Anping County Baitong wire mesh products Co., Ltd
Home ProductsJohnson Wire Screen

304 Ss Thread Joint 0.35mm Slot Johnson Screen Pipe For Water Filter

I'm Online Chat Now

304 Ss Thread Joint 0.35mm Slot Johnson Screen Pipe For Water Filter

large.img.alt
small.img.alt small.img.alt

Large Image :  304 Ss Thread Joint 0.35mm Slot Johnson Screen Pipe For Water Filter

Product Details:
Place of Origin: China
Brand Name: BT
Certification: ISO9001
Model Number: Johnson Wedge Wire Screen
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Wooden Boxes or Pallets
Delivery Time: 5-25days
Payment Terms: T/T
Supply Ability: 1000 pcs per day
Detailed Product Description
Product Name: Johnson Screen Other Name: Stianless Steel 0.35mm Slot Height 100mm For Water Filter Tube
Material: Stainless Steel Wire, 304, 316L,904L Technique: Welded Mesh,Spot Welded, Wire Wraped
Application: Filters,Sluge Filter,Reactor Internals,Ion Exchanger Slot Size: 0.2-0.02mm +- 0.005mm
Feature: Anti-corrosion, Durable, Corrosion Resistant, Heat Resistant, Water Well Drilling Cylinder Filter Rating: 94%
Length: Can Be Customized For You Sample: Yes And Can Be Customized
Color: Silver Wedge Wire: 0.75 Mmx1.5mm Or As Customer's Request
Weave Style: Welded
High Light:

0.35mm slot johnson screen pipe

,

0.35mm slot johnson wire screen

,

304 ss johnson screen pipe

Stainless Steel Johnson Screen Pipe With Thread Joint For Water Filter





Johnson wire screen information:



Johnson screen is used for filtration of petrochemical equipment, coal washing plant, well drilling, sewage treatment, food, etc.
It can be used with a deep well pump and submersible pump. At present, domestic water Wells do not use this kind of filter pipe, one is because of the high cost, two, the domestic Wells are not deep enough to the sand layer, only some hot spring companies use, because their Wells are thousands of meters deep.Most current screens use trapezoidal filaments.



Johnson wire screen Specification:



Material

Stainless Steel

Grade

205, 304,304L, 316L

O.D

89mm 117mm 219mm 273mm 325mm

Size

3-1/2" 4-1/2" 8-5/8 " 10-3/4" 12"

Slot size

0.5 mm,0.63mm, 0.75mm, 1.0mm

Length

2.9m / 5.8 m, 100-6000mm

End connection

Welded rings/screws

Wire size

63# 93# 118 #                          Support rod:140 #

Wire Shape

V Shape



Johnson wire screen Advantage:



1. The continuous gap greatly increases the water passing area, so the contact with the aquifer is better.
2. The V-shaped section structure avoids blockage and ensures smooth circulation.
3. Continuous pores can be used effectively for a long time.
4. The trapezoidal filter pipe has a strong structure, high porosity and precise gap size.
5. The trapezoidal wire water filter tube is easy to backwash, has a long service life, is safe and reliable, and has a low overall cost



Johnson wire screen Characteristics:



Stainless Steel 304 / 316 Wedge Wire Wrapped Slotted Screen Pipe For Filteration

Not easy to jam

the special V-shaped wire, make the hole of the screen outside face is smaller than inside,

so the hole is not easy to jam.

Slot even The CNC machine tools strictly control the gap between the wire so that the gap is even.

Strong corrosion resistance

Stainless steel 304 have the high corrosion resistance



Johnson wire screen Application:



Stainless Steel 304 / 316 Wedge Wire Wrapped Slotted Screen Pipe For Filteration

1. Heavy oil, sand oil, light oil, SAGD, CBM, bitumen, thermal

2. Water injection, bi-modal sand, carbonates, thin pay

3. Horizontal, vertical, deviated oil and gas and water wells



Johnson write screen Packing&Delivery:



304 Ss Thread Joint 0.35mm Slot Johnson Screen Pipe For Water Filter 0

304 Ss Thread Joint 0.35mm Slot Johnson Screen Pipe For Water Filter 1

304 Ss Thread Joint 0.35mm Slot Johnson Screen Pipe For Water Filter 2
